ComposePipelines#

class augraphy.utilities.composepipelines.ComposePipelines(pipelines)[source]#

Bases: object

The composition of multiple AugraphyPipelines. Define AugraphyPipelines elsewhere, then use this to compose them. ComposePipelines objects are callable on images (as numpy.ndarrays).

Parameters:: pipelines (list or tuple) – A list contains multiple augraphy.base.AugraphyPipeline.

Overview#

ComposePipelines allows the composition of multiple AugraphyPipelines. The consecutive pipelines will be applied on the output of prior pipeline. The output of ComposePipelines is a dict and the name of final output will be in the format of “pipeline(n-1)-output”, where n is the number of total pipelines.

Example#

In this example, ComposePipelines is use to compose three different pipelines.

# import libraries
from augraphy import *
import cv2
import numpy as np
from augraphy.utilities.composepipelines import ComposePipelines

# initialize pipeline1
ink_phase1   = [InkBleed(p=1)]
paper_phase1 = [DirtyRollers(p=1)]
post_phase1  = [WaterMark(p=1)]
pipeline1    = AugraphyPipeline(ink_phase1, paper_phase1, post_phase1)

# initialize pipeline2
ink_phase2   = [BleedThrough(p=1)]
paper_phase2 = [DirtyDrum(p=1)]
post_phase2  = [Faxify(p=1)]
pipeline2    = AugraphyPipeline(ink_phase2, paper_phase2, post_phase2)

# initialize pipeline3
ink_phase3   = [Letterpress(p=1)]
paper_phase3 = [BadPhotoCopy(p=1)]
post_phase3  = [Folding(p=1)]
pipeline3    = AugraphyPipeline(ink_phase3, paper_phase3, post_phase3)

# compose pipelines
compose_pipeline = ComposePipelines([pipeline1, pipeline2, pipeline3])

# create input image
image = np.full((1200, 1200,3), 250, dtype="uint8")
cv2.putText(
    image,
    "Lorem ipsum dolor sit amet, consectetur adipiscing elit",
    (80, 250),
    cv2.FONT_HERSHEY_SIMPLEX,
    1.2,
    0,
    3,
)

# augment image
augmented_image = compose_pipeline(image)["pipeline2-output"]

Input image:

Augmented image:
